Regular price
Rs. 3,999.00
Regular price
Rs. 6,999.00
Sale price
Rs. 3,999.00
LED Indicator Status
Red light
Always Light ON - Charging / Lights Off - Fully Charged
Yellow light
Quick Flash - Can not identify SIM Card / Slow Flash - GSM Initialization / Always Lights On - GSM Signal is well received
Blue light
Quick Flash(2 times per second) - Bad GPS / Slow Flash ( a time per second ) - Searching GPS Signal / Always Lights On - GPS Signal is well received
GSM Specifications
Gsm frequency
GSM 850/900/1800/1900MHz
Class 12,tcp/ip build in gsm module
0.001 kg
Max output
GSM 850/900MHz (32.5dBm +-2dBm) GSM 1800/1900MHz (30dBm +-2dBm)
Max frequency error
+-0.1ppm
Receive sensitivity
Class II RBER2%(-103dBm)
Other Specifications
Voice monitor range
<= 5meters
Charging voltage
DC 5V/600mA (type-c)
Size
85 x 61 x 31 mm
Location way
Working temperature
-25 to +75 degree celsius
Storage temperature
-40 to +85 degree celsius
Device weight
226 Gram
Communication way
TCP
Battery
10000 mAh
GPS Specifications
Gps chipset
MTK
Frequency
Glonass,1602MHz;GPS, 1575.42MHz
Channels
22 track channels, 66 acquire channels
Location accuracy
<5 meters
Tracking sensitivity
-162 dBm
Capture sensitivity
- 148dBm
Ttff (open sky)
Hot Start:5s Warm start :30s Cold start:40s
